Server Rack 19 Inch Network Cabinet With Doors

Payment Type: T/T,Western Union
Incoterm: FOB,CFR,CIF
Min. Order: 1 Set/Sets
Delivery Time: 5 Days

Basic Info

Model No.: SJ-NC-3

Type: Optical Fiber Distribution Box

Wiring Devices: ODF

Certification: RoHS, ISO

Condition: New

Model No.: SJ-NC-3

Color:: Customized

Installation:: Free Standing

Material:: SPCC Quality Cold Rolling Steel

Cabinet standard :: 19'' inch inner installation

Loading Capability:: 800KGS

Surface Treatment:: Degreasing,Pickling,Phosphating,Powder Coated

Product Specification:: 18U-47U

Width:: 600mm,800mm

Depth:: 600mm,800mm,900mm,1000mm,1200mm

Additional Info

Packaging: Standard Export Carton

Productivity: 20000sets/week

Brand: OEM or Sijee

Transportation: Ocean,Air

Place of Origin: China

Supply Ability: 5000000sets/year

Certificate: ISO, Rohs

HS Code: 853670000

Port: Ningbo,Shanghai

Product Description

SJ-NC-3  Server Rack 19 Inch Network Cabinet With Doors

This network cabinet is widely used for installing and placing of 19" international standard equipment and the system
integration;
The product conforms to ANSI/EIA, RS-310-D, IEC297-2, DIN41491:PART1, DIN41494:PART7 and GB/T3047.2-92
standards and provides reliable installation, support, power supply and ventilation device and effectively protect system e
quipment.

Product Features:
1.Adopts good-quality steel plate, strongly rigid; surface decreasing, anti-rust phosphorescence, plastic-spray treatment,
thus having a beautiful appearance.
2.All options adopt 19" standard installation, suitable for 19" standard rack, equipment cabinet of metric and ETIS
standards, etc.
3.Complete in types and specifications; various customized cabinets are available upon request;
4.Related routing holes reserved on the upper and lower covers for free cabling;
5.Sufficient routing space in the cabinet with routes designed on all sides;
6.Side door detachable and professional components for cabinet combining;
7.Safe and reliable ground protection;
8.Protection grade: IP20.

Standards Conformed to:
GB/T3047.2-92 Standards
ANSI/EIA;RS-310-D
IEC297-2
DIN41491:PART1
DIN41494:PART7


Specification:

Product name :Network cabinet

(1) Brand name : Sijee or OEM

(2)Product specification:

Height:18U-47U

Width: 600mm, 800mm

Depth:600mm,800mm,900mm,1000mm,1200mm

(3) Certification :ISO9001,TLC, OHSAS 18001, ISO 14001

(4)Cabinet standard :19'' inch inner installation

(5)Material :High quality SPCC cold rolled steel T:1.2-2.0mmEnclosure: 5-fold profiled sheet steel 1.5mmDoor Plate: sheet steel 2.0mmRear Plate: sheet steel 1.5mmMounting plate: Zinc-plate 2.0mm-3.0mm

(6)Place of origin :Ningbo or Shanghai China (mainland)

(7)Color :Black, White or Grey (Special Color on Request)

(8)MOQ:1piece

(9)Loading Capacity:800KGS

(10)Installation :19'' inch inner installation

(11)Surface Treatment :Box & Door: Phosphating, Electrostatic powder spraying in orange-peel or plain finish

(12)Delivery details:15 working days.

(13)Packing:(a) Film around the spare parts.(b) EPE corner protectors in the four corners of carton.

(c) High quality cartons with strip.

(14)Accessories

Cooling fan:800mm deep or below with two fans; 800mm deep include 800mm with four fans.

PDU:A set of six universal power socket

Castor and support:Four M12 adjustable foot, four 2" heavy-duty casters

(15)Comments1. Overall dimension could be custom made by requirement. 2. Configuration of Box can be customized according to customer requirement.


View of product:

Server Rack Cabinet

Network Racks

More Product:

Network cabinet

rack mount optical distribution box

Industrial Enclosure

Sheet Metal Workshop:

metal wall mounted enclosure

wall mounted enclosure

Certification:

ISO 9001

Environmental ISO14001


Fiber optic distribuiton box ROHS

You are manufacturer or trading company?

We are 15-year-experience manufacturer of sheet metal fabrication,handle almost anything from metal. You can get quotation of direct factory which give you advantage in target market.

What is the lead time for prototype? Do you help repairing the parts of the nonconforming sample?

Normally 5 days for prototyping, and we help with sample repairing.If sample is non-conformity,we can also make second sample for free to improve the quality, client just need to pay the freight.

You factory is a huge one?

We have an area of 30000 square meters for production & assembly,and now have over 225 employees.Assembling & packaging place covers over 5000 square meter,clients can save the cost of assembly in target market.

What is your brand service?

High quality stainless steel fabrication & precision pressing & powder coating are our brand work.

How to start cooperation with you?

Type A:Clients send us technical drawing>quotation on drawings>confirmation on between>prototype>sample confirmation>package confirmation>batch order

Type B:Clients send us ideas or sample>technical drawing design>quotation on drawings>confirmation on between>prototype>sample confirmation>package confirmation>batch order
